Low-speed Elevator Cable

Name: Low-speed Elevator Cable
Brand: Aupins Technology Co., Ltd.

A new type of oil-resistant flexible special sheath is adopted, which can still maintain softness and flame retardancy at a low temperature of -15°C. All data on product performance and service life are verified by experimental tests.

Cable parameters:

1. Running speed: ≦4m/s

2. Travelling height: ≦80m

3. Passed 3 million flex tests.

4. Operating temperature:-15℃~+70℃

5. Certificate:RoHS,CE,CCC

6. Standard:GBT5023.6,IEC60227-6.

7. Sheath:PVC for elevator cable

8. Insulation:PVC

9. Rated Voltage:300/500V

10. Shield: Copper or Tinned copper

11. Voltage withstand : 2000V/5min

(Communication units are customized according to customer needs.)

Get a Quote 

Specification of Low-speed Elevator Cable

Type	Cores	Conductor		Insulation	Shielded wires	Approximate diameter		Electrical characteristics
Type	Cores	Cross section (mm2)	App. dia. (mm)	App. dia. (mm)	P20.75 pairs	Thickness (mm)	Width（mm）	Conductor resistance（20℃） Ω/km
TVVBP 6 core	24	0.75	1.1	2.1	2（According to customer needs increase or decrease）	9.0	43.6	≤26.0
	30						52.1
	36						58.4
	42						64.7
	48						71.0
	54						77.3
	60						83.6
	24	1.0	1.34	2.6		11.4	51.6	≤19.5
	30						61.9
	36						69.7
	42						77.5
	48						85.3
	54						93.1
	60						100.9
TVVBG-TV	12×0.75+1×1.5+2P×2×0.5	0.75	1.1	2.4		5.6	49.0	≤26.0
	14×0.75+1×1.5+2P×2×0.5					5.6	52.0
	16×0.75+1×1.5+1P×2×0.5					5.6	55.0
	16×0.75+1×1.5+2P×2×0.5					5.6	58.0
	16×0.75+1×1.5+3P×2×0.5					5.6	62.0
	18×0.75+1×1.5+1P×2×0.5					5.6	58.0
	18×0.75+1×1.5+2P×2×0.5					5.6	63.0
	19×0.75+1×1.5+1P×2×0.5					5.6	62.0
	20×0.75+1×1.5+1P×2×0.5					5.6	67.0
	20×0.75+1×1.5+2P×2×0.5					5.6	70.0
	22×0.75+1×1.5+1P×2×0.5					5.6	72.0

Type	Cores	Conductor
		Cross section (mm2)
ETT	≥2	20-2AWG
ETP	≥2
AP can customize cables for customers, the products shown are only a part, and more models can be obtained online for more information
